Vibratory Screening Machine

Product description

The rotary vibrating screen is a highly precise screening equipment with an exquisite design. It adopts a fully enclosed structure, which can effectively prevent dust from flying and ensure the cleanliness and safety of the production environment. This equipment features high screening efficiency, good anti-blocking performance, smooth and quiet operation. By simply adjusting the parameters, it can flexibly adapt to different material characteristics and classification requirements. The screen mesh can be replaced easily, and the maintenance cost is low. Due to its excellent versatility and reliability, it is widely used in production processes of various fields such as food, chemical industry, ceramics, and new materials.

Working principle
The power core of the rotary screen is a vertical vibration motor installed on the top of the equipment. At both ends of the motor shaft, adjustable eccentric blocks are installed. When the motor rotates at high speed, the eccentric blocks generate a strong centrifugal force.
This centrifugal force will drive the screening machine to produce a three-dimensional compound motion. You can understand it as:
A horizontal rotational movement, which is responsible for evenly distributing the materials and spreading them out in a spiral pattern;
A vertical up-and-down vibration, which is responsible for making the materials jump on the screening surface, thereby effectively preventing the clogging of the sieve holes and accelerating the screening of fine particles.
The three-dimensional trajectory formed by these two movements enables the materials to be fully dispersed on the sieve surface and efficiently stratified, thereby achieving rapid screening, classification and solid-liquid separation. By adjusting the relative angle of the upper and lower eccentric blocks, the movement trajectory of the materials and the screening speed can be precisely controlled.

Features & Benefits

1. High efficiency and high precision: The unique composite vibration mode ensures rapid dispersion and screening of materials, with high screening efficiency and accurate precision.
2. Excellent anti-blocking performance: Intense vertical vibration effectively cleans the screen mesh, significantly reducing the risk of screen hole blockage.
3. Environmentally friendly and dust-free: The fully enclosed structure design completely eliminates dust dispersion, ensuring a clean and safe working environment.
4. Stable operation and low energy consumption: The equipment operates smoothly, has low noise, low energy consumption, and a long service life.
5. Flexible and convenient adjustment: By simply adjusting, the movement state of the materials can be changed, easily adapting to various process requirements.
6. Simple maintenance: The screen mesh replacement is quick, the core components are sturdy and durable, effectively reducing maintenance costs.

Product parameter

Production line diagram

1. Vacuum feeding into the mixer, automated, dust-free
2. The mixed materials directly enter the sieve machine for screening

Detail display
